Product Summary
The 1P620 Pico Xinger is a low profile, miniature 20dB directional coupler
in an easy to use surface mount package designed for MMDS and WLAN
applications. The 1P620 is for power and frequency detection as well as
power injection. The 1P620 is an ideal solution for the ever-increasing
demands of the wireless industry for smaller printed circuit boards and high
performance.
Parametrics
Parts have been subjected to rigorous qualification testing and units are
100% tested. They are manufactured using materials with x and y thermal
expansion coefficients compatible with common substrates such as FR4, G-
10, RF-35, RO4003 and polyimide. Available in both 5 of 6 tin lead (1P620)
and 6 of 6 RoHS compliant tin immersion (1P620S).
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1P620S |
Anaren |
Signal Conditioning 2.3-2.7GHz IL:.25dB VSWR:1.22 -55 to 85C |
Data Sheet |
|
|
|||||||||
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||
1P620 |
Other |
Data Sheet |
Negotiable |
|
||||||||||
1P620S |
Anaren |
Signal Conditioning 2.3-2.7GHz IL:.25dB VSWR:1.22 -55 to 85C |
Data Sheet |
|
|
