Product Summary
The TriQuint AH314-G is a high dynamic range broadband driver amplifier in a surface mount package. The two-stage amplifier has 23 dB of gain, while achieving +25dBm of linear output power for 2.3 to 2.9 GHz applications.
Parametrics
The AH314-G uses a high reliability +5V InGaP / GaAs HBT process technology. The device incorporates proprietary bias circuitry to compensate for variations in linearity and current draw over temperature. An internal active bias allows the AH314-G to operate directly off a commonly available +5V supply. The RoHS-compliant / lead-free 5x5mm QFN package is surface mountable to allow for low manufacturing costs to the end user. The AH314-G is also package and pin compatible with the 3.3 - 3.8 GHz AH315-G and the 0.7 - 2.7 GHz AH323-G.
The AH314-G is targeted for use in a configuration for the driver stage amplifier in next generation base stations where high linearity and medium power is required.
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
AH314-G |
TriQuint Semiconductor |
RF Amplifier 2300-2900MHz 23dB |
Data Sheet |
|
|
|||||||||||||||
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||||
AH31 |
Other |
Data Sheet |
Negotiable |
|
||||||||||||||||
AH312 |
Other |
Data Sheet |
Negotiable |
|
||||||||||||||||
AH312-S8G |
TriQuint Semiconductor |
RF Amplifier 400-2300MHz 18dB Gain@900MHz |
Data Sheet |
|
|
|||||||||||||||
AH312-S8PCB900 |
TriQuint Semiconductor |
RF Development Tools 900MHz Eval Brd 18dB Gain |
Data Sheet |
|
|
|||||||||||||||
AH314-G |
TriQuint Semiconductor |
RF Amplifier 2300-2900MHz 23dB |
Data Sheet |
|
|
|||||||||||||||
AH314-PCB |
TriQuint Semiconductor |
RF Development Tools 2.4-2.7GHz Eval Brd 23dB Gain |
Data Sheet |
|
|
